Toshiba B-EP2DL Series System Mode Manual

4. SYSTEM MODE (For Service Persons and System Administrators) EO13-33005
4.6 Test Print
4- 57
(3) Sensor type selection
This setting selects a print type, auto mode using the strip sensor or fixed mode (BATCH or STRIP)
regardless of a sensor status.
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE]
key is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this setting, repeat
mode is enabled and the key pressed is repeatedly entered.
4. The change in the parameter setting becomes effective when the [POWER] key is pressed after
setting, then stored in the backup memory.
5. The default value at power on is AUTO (Print depending on the sensor used).
(4) Label Length Setting (LABEL LEN.)
Select a label length for the test print from a range of 5 mm to 999 mm. (Default is 63mm at power ON)
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE]
key is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this setting, repeat
mode is enabled and the key pressed is repeatedly entered.
4. The change in the parameter setting becomes effective when the [POWER] key is pressed after
setting, then stored in the backup memory.
5. The default value at power on is 63mm.
6. The label length, which is larger than the image buffer length, cannot be specified. If specified, the
printer prints the data of image buffer length, then stops.
TYPE AUTO
TYPE STRIP
[FEED]
[PAUSE]
TYPE BATCH
Print depending on the sensor used (Factory default)
Fixed to strip issue
Fixed to batch issue
[FEED]
[PAUSE]
LABEL LEN. 5mm
LABEL LEN. 6mm
LABEL LEN. 7mm
LABEL LEN. 997mm
LABEL LEN. 998mm
LABEL LEN. 999mm
Short Label
Long Label
