Encompass 4 Reader System Guide
D-12
529 Display presence input status PRST Px D0 Ax Tx Ix
P0 = disable presence w/o tag
reports

P1 = enable presence w/o tag
reports
D0 = min presence true period 
of 0 ms
A0 = RF off on timeout
A1 = RF off on timeout or tag
A2 = RF off on timeout or no
presence
T0: RF timeout of 0 ms (always
expired)
T1: RF timeout of 4 ms
T2: RF timeout of 8 ms
T3: RF timeout of 12 ms
T4: RF timeout of 20 ms
T5: RF timeout of 24 ms
T6: RF timeout of 32 ms
T7: RF timeout of 48 ms
T8: RF timeout of 60 ms
T9: RF timeout of 92 ms
TA: RF timeout of 152 ms
TB: RF timeout of 300 ms
TC: RF timeout of 452 ms
TD: RF timeout of 600 ms
TE: RF timeout of 752 ms
TF: RF timeout infinite, never
expires (factory default)
I0 = Input inversion disabled
(factory default)

I1 = Input inversion enabled
530 Display RF0 filter status RF0S Ux Vx 
U0 = one ID separation
U1 = two ID separations
U2 = three ID separations
U3 = four ID separations
U4 = transmit all IDs
V0 = valid ID code criteria of
one acquisition (fixed)

V1 = valid ID code criteria of two
acquisitions

V2 = valid ID code criteria of
three acquisitions
V3 = valid ID code criteria of
four acquisitions
532 Display Wiegand mode status T0F x
0 = disabled
1 = enabled
533 Display Wiegand retransmit
interval
WTI xx 
xx = 01–FF seconds
Table D-2 Encompass 4 Reader Commands Listed Numerically (continued)
Number Command Name Reader Message
