Vacon 100 flow Applications Manual

Table 46: Analogue input 3 settings
Index Parameter Min Max Unit Default ID Description
P3.5.2.3.1 AI3 Signal Selection
AnIN
SlotD.1
141
See P3.5.2.1.1.
P3.5.2.3.2
AI3 Signal Filter
Time
0.00 300.00 s 0.1 142
See P3.5.2.1.2.
P3.5.2.3.3 AI3 Signal Range 0 1 0 143 See P3.5.2.1.3.
P3.5.2.3.4 AI3 Custom. Min -160.00 160.00 % 0.00 144 See P3.5.2.1.4.
P3.5.2.3.5 AI3 Custom. Max -160.00 160.00 % 100.00 145 See P3.5.2.1.5.
P3.5.2.3.6 AI3 Signal Inversion 0 1 0 151 See P3.5.2.1.6.
Table 47: Analogue input 4 settings
Index Parameter Min Max Unit Default ID Description
P3.5.2.4.1 AI4 Signal Selection
AnIN
SlotD.2
152
See P3.5.2.1.1.
P3.5.2.4.2
AI4 Signal Filter
Time
0.00 300.00 s 0.1 153
See P3.5.2.1.2.
P3.5.2.4.3 AI4 Signal Range 0 1 0 154 See P3.5.2.1.3.
P3.5.2.4.4 AI4 Custom. Min -160.00 160.00 % 0.00 155 See P3.5.2.1.4.
P3.5.2.4.5 AI4 Custom. Max -160.00 160.00 % 100.00 156 See P3.5.2.1.5.
P3.5.2.4.6 AI4 Signal Inversion 0 1 0 162 See P3.5.2.1.6.
Table 48: Analogue input 5 settings
Index Parameter Min Max Unit Default ID Description
P3.5.2.5.1 AI5 Signal Selection
AnIN
SlotE.1
188
See P3.5.2.1.1.
P3.5.2.5.2
AI5 Signal Filter
Time
0.00 300.00 s 0.1 189
See P3.5.2.1.2.
P3.5.2.5.3 AI5 Signal Range 0 1 0 190 See P3.5.2.1.3.
P3.5.2.5.4 AI5 Custom. Min -160.00 160.00 % 0.00 191 See P3.5.2.1.4.
P3.5.2.5.5 AI5 Custom. Max -160.00 160.00 % 100.00 192 See P3.5.2.1.5.
P3.5.2.5.6 AI5 Signal Inversion 0 1 0 198 See P3.5.2.1.6.
VACON · 142 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
