Vacon 100 flow Applications Manual

Table 50: Digital output settings on standard I/O board, Slot B
Index Parameter Min Max Unit Default ID Description
P3.5.3.2.1 RO1 Function 0 74 Varies 11001
26 = Time channel 2
27 = Time channel 3
28 = FB ControlWord
B13
29 = FB ControlWord
B14
30 = FB ControlWord
B15
31 = FB Process-
Data1.B0
32 = FB Process-
Data1.B1
33 = FB Process-
Data1.B2
34 = Maintenance
alarm
35 = Maintenance fault
36 = Block 1 Out
37 = Block 2 Out
38 = Block 3 Out
39 = Block 4 Out
40 = Block 5 Out
41 = Block 6 Out
42 = Block 7 Out
43 = Block 8 Out
44 = Block 9 Out
45 = Block 10 Out
46 = Jockey pump con-
trol
47 = Priming pump
control
48 = Auto-cleaning
active
49 = Multi-pump K1
control
50 = Multi-pump K2
control
51 = Multi-pump K3
control
52 = Multi-pump K4
control
53 = Multi-pump K5
control
54 = Multi-pump K6
control
PARAMETERS MENU VACON · 145
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
