Table 50: Digital output settings on standard I/O board, Slot B
Index Parameter Min Max Unit Default ID Description
P3.5.3.2.1 RO1 Function 0 74 Varies 11001
55 = Multi-pump K7
control
56 = Multi-pump K8
control
69 = Selected parame-
ter set
72 = AHF Cap Discon-
nect
73 = AHF Cap Discon-
nect Inv
74 = Run indication
P3.5.3.2.2 RO1 ON Delay 0.00 320.00 s 0.00 11002
P3.5.3.2.3 RO1 OFF Delay 0.00 320.00 s 0.00 11003
P3.5.3.2.4 RO2 Function 0 56 Varies 11004 See P3.5.3.2.1.
P3.5.3.2.5 RO2 ON Delay 0.00 320.00 s 0.00 11005 See M3.5.3.2.2.
P3.5.3.2.6 RO2 OFF Delay 0.00 320.00 s 0.00 11006 See M3.5.3.2.3.
P3.5.3.2.7 RO3 Function 0 56 Varies 11007
See P3.5.3.2.1. Shows
if more than 2 output
relays are installed.
* = The selection of the application with parameter P1.2 Application gives the default value.
See the default values in 12.1 The default values of parameters in the different applications.
THE DIGITAL OUTPUTS OF THE EXPANDER SLOTS C, D AND E
Shows only the parameters for the outputs on option boards in slots C, D and E. Make the
selections as in RO1 Function (P3.5.3.2.1).
This group or these parameters do not show, if there are no digital outputs in slots C, D or E.
VACON · 146 PARAMETERS MENU
5
