Table 51: Standard I/O board analogue output settings, Slot A
Index Parameter Min Max Unit Default ID Description
P3.5.4.1.1 AO1 function 0 31 2 * 10050
0 = TEST 0% (Not used)
1 = TEST 100%
2 = Output freq (0 -
fmax)
3 = Freq reference (0 -
fmax)
4 = Motor speed (0 -
Motor nominal speed)
5 = Output current (0 -
I
n
Motor)
6 = Motor torque (0 -
T
n
Motor)
7 = Motor power (0 -
P
n
Motor)
8 = Motor voltage (0 -
U
n
Motor)
9 = DC link voltage (0 -
1000V)
10 = PID Setpoint
(0-100%)
11 = PID Feedback
(0-100%)
12 = PID1 output
(0-100%)
13 = Ext.PID output
(0-100%)
14 = ProcessDataIn1
(0-100%)
15 = ProcessDataIn2
(0-100%)
16 = ProcessDataIn3
(0-100%)
PARAMETERS MENU VACON · 147
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5
