Selection
number
Selection name Description
0
Test 0% (Not used) The analogue output is set to 0% or 20% so that it agrees
with parameter P3.5.4.1.3.
1
TEST 100% The analogue output is set to 100% of the signal (10V /
20mA).
2
Output frequency The actual output frequency from 0 to Maximum frequency
reference.
3
Frequency reference The actual frequency reference from 0 to Maximum fre-
quency reference.
4 Motor speed The actual motor speed from 0 to Motor nominal speed.
5
Output current The output current of the drive from 0 to Motor nominal cur-
rent.
6
Motor torque The actual motor torque from 0 to motor nominal torque
(100%).
7
Motor power The actual motor power from 0 to Motor nominal power
(100%).
8 Motor voltage The actual motor voltage from 0 to Motor nominal voltage.
9 DC-link voltage The actual DC-link voltage 0…1000V.
10 PID Setpoint The actual setpoint value of the PID Controller (0…100%).
11 PID Feedback The actual feedback value of the PID Controller (0…100%).
12 PID output The output of the PID controller (0…100%).
13 ExtPID output The External PID controller output (0…100%).
14
Fieldbus Process Data In 1 Fieldbus Process Data In 1: 0…10000 (this agrees with 0…
100.00%).
15
Fieldbus Process Data In 2 Fieldbus Process Data In 2: 0…10000 (this agrees with 0…
100.00%).
16
Fieldbus Process Data In 3 Fieldbus Process Data In 3: 0…10000 (this agrees with 0…
100.00%).
17
Fieldbus Process Data In 4 Fieldbus Process Data In 4: 0…10000 (this agrees with 0…
100.00%).
18
Fieldbus Process Data In 5 Fieldbus Process Data In 5: 0…10000 (this agrees with 0…
100.00%).
19
Fieldbus Process Data In 6 Fieldbus Process Data In 6: 0…10000 (this agrees with 0…
100.00%).
20
Fieldbus Process Data In 7 Fieldbus Process Data In 7: 0…10000 (this agrees with 0…
100.00%).
PARAMETER DESCRIPTIONS VACON · 277
