Vacon 100 flow Applications Manual

Selection
number
Selection name Description
21
Fieldbus Process Data In 8 Fieldbus Process Data In 8: 0…10000 (this agrees with 0…
100.00%).
22
Block Out.1 The output of the programmable Block 1: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
23
Block Out.2 The output of the programmable Block 2: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
24
Block Out.3 The output of the programmable Block 3: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
25
Block Out.4 The output of the programmable Block 4: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
26
Block Out.5 The output of the programmable Block 5: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
27
Block Out.6 The output of the programmable Block 6: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
28
Block Out.7 The output of the programmable Block 7: 0…10000 (this
agrees with 0…100,00%). See parameter menu M3.19 Drive
customizer.
29
Block Out.8 The output of the programmable Block 8: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
30
Block Out.9 The output of the programmable Block 9: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
31
Block Out.10 The output of the programmable Block 10: 0…10000 (this
agrees with 0…100.00%). See parameter menu M3.19 Drive
customizer.
P3.5.4.1.2 AO1 FILTER TIME (ID 10051)
Use this parameter to set the filtering time for the analog signal.
The filtering function is disabled when the filtering time is 0. See P3.5.2.1.2.
P3.5.4.1.3 AO1 MINIMUM (ID 10052)
Use this parameter to change the range of the analogue output signal.
For example, if '4mA' is selected, the range of analogue output signal is 4..20mA.
Select the signal type (current/voltage) with the dip switches. The analogue output scaling is
different in P3.5.4.1.4. See also P3.5.2.1.3.
VACON · 278 PARAMETER DESCRIPTIONS
10
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
