Vacon 100 flow Applications Manual

Table 123: The default values of parameters in the different applications
Index Parameter Default Unit ID Description
A B C D E
P3.2.1 Remote Control
Place
0 0 0 0 0 172 0 = I/O Control
P3.2.2 Local/Remote 0 0 0 0 0 211 0 = Remote
P3.2.6 I/O A Logic 2 2 2 0 0 300 0 = Forw-Back
2 = Forw-Back
(edge)
P3.2.7 I/O B Logic 2 2 2 2 2 363 2 = Forw-Back
(edge)
P3.3.1.5 I/O A Reference
Selection
6 6 7 7 7 117 6 = AI1 + AI2
7 = PID
P3.3.1.6 I/O B Reference
Selection
4 4 4 4 4 131 4 = AI1
P3.3.1.7 Keypad Refer-
ence Selection
2 2 2 2 2 121 2 = Keypad Refer-
ence
P3.3.1.10 Fieldbus Refer-
ence Selection
3 3 3 3 3 122 3 = Fieldbus Ref-
erence
P3.3.3.1 Preset Fre-
quency Mode
0 0 0 0 0 182 0 = Binary Coded
P3.3.3.3 Preset Fre-
quency 1
10.0 10.0 10.0 10.0 10.0 Hz 105
P3.3.3.4 Preset Fre-
quency 2
15.0 15.0 15.0 15.0 15.0 Hz 106
P3.3.3.5 Preset Fre-
quency 3
20.0 20.0 20.0 20.0 20.0 Hz 126
P3.3.6.1 Flushing Refer-
ence Activation
0 0 0 0 101 530 0 = DigIN Slot0.1
101 = DigIN SlotA.
2
P3.3.6.2 Flushing Refer-
ence
0 0 0 0 0 Hz 1239
P3.5.1.1 Ctrl SIgnal 1 A 100 100 100 100 100 403 100 = DigIN SlotA.
1
