Vacon 100 flow Applications Manual

Table 123: The default values of parameters in the different applications
Index Parameter Default Unit ID Description
A B C D E
P3.5.1.2 Ctrl SIgnal 2 A 101 101 0 0 0 404 0 = DigIN Slot0.1
101 = DigIN SlotA.
2
P3.5.1.4 Ctrl SIgnal 1 B 0 0 103 101 0 423 0 = DigIN Slot0.1
101 = DigIN SlotA.
2
103 = DigIN SlotA.
4
P3.5.1.7 I/O B Control
Force
0 0 105 102 0 425 0 = DigIN Slot0.1
102 = DigIN SlotA.
3
105 = DigIN SlotA.
6
P3.5.1.8 I/O B Reference
Force
0 0 105 102 0 343 0 = DigIN Slot0.1
102 = DigIN SlotA.
3
105 = DigIN SlotA.
6
P3.5.1.9 Fieldbus Control
Force
0 0 0 0 0 411
P3.5.1.10 Keypad Control
Force
0 0 0 0 0 410
P3.5.1.11 External Fault
(Close)
102 102 101 0 105 405 0 = DigIN Slot0.1
101 = DigIN SlotA.
2
102 = DigIN SlotA.
3
105 = DigIN SlotA.
6
P3.5.1.13 Fault Reset
(Close)
105 105 102 0 103 414 0 = DigIN Slot0.1
102 = DigIN SlotA.
3
103 = DigIN SlotA.
4
105 = DigIN SlotA.
6
P3.5.1.21 Preset Freq
Selection 0
103 103 104 0 0 419 0 = DigIN Slot0.1
103 = DigIN SlotA.
4
104 = DigIN SlotA.
5
P3.5.1.22 Preset Freq
Selection 1
104 104 0 0 0 420 0 = DigIN Slot0.1
104 = DigIN SlotA.
5
VACON · 382 APPENDIX 1
12
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
