Vacon 100 flow Applications Manual

Table 123: The default values of parameters in the different applications
Index Parameter Default Unit ID Description
A B C D E
P3.5.1.23 Preset Freq
Selection 2
0 0 0 0 0 421
P3.5.1.31 PID Setpoint
Selection
0 0 0 0 102 1047 0 = DigIN Slot0.1
102 = DigIN SlotA.
3
P3.5.1.36 Flushing Refer-
ence Activation
0 0 0 0 101 530 0 = DigIN Slot0.1
101 = DigIN SlotA.
2
P3.5.1.42 Pump 1 Inter-
lock
0 0 0 103 0 426 0 = DigIN Slot0.1
103 = DigIN SlotA.
4
P3.5.1.43 Pump 2 Inter-
lock
0 0 0 104 0 427 0 = DigIN Slot0.1
104 = DigIN SlotA.
5
P3.5.1.44 Pump 3 Inter-
lock
0 0 0 105 0 428 0 = DigIN Slot0.1
105 = DigIN SlotA.
6
P3.5.2.1.1 AI1 Signal
Selection
100 100 100 100 100 377 100 = AnIN SlotA.
1
P3.5.2.1.2 AI1 Filter Time 0.1 0.1 0.1 0.1 0.1 s 378
P3.5.2.1.3 AI1 Signal
Range
0 0 0 0 0 379 0 = 0…10V / 0…20
mA
P3.5.2.1.4 AI1 Custom Min 0.0 0.0 0.0 0.0 0.0 380
P3.5.2.1.5 AI1 Custom Max 100.0 100.0 100.0 100.0 100.0 % 381
P3.5.2.1.6 AI1 Signal Inver-
sion
0 0 0 0 0 387
P3.5.2.2.1 AI2 Signal
Selection
101 101 101 101 101 388 101 = AnIN SlotA.
2
P3.5.2.2.2 AI2 Filter Time 0.1 0.1 0.1 0.1 0.1 s 389
P3.5.2.2.3 AI2 Signal
Range
1 1 1 1 1 390 1 = 2…10V / 4…20
mA
P3.5.2.2.4 AI2 Custom Min 0.0 0.0 0.0 0.0 0.0 391
P3.5.2.2.5 AI2 Custom Max 100.0 100.0 100.0 100.0 100.0 % 392
APPENDIX 1 VACON · 383
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
12

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
