Vacon 100 flow Applications Manual

Table 123: The default values of parameters in the different applications
Index Parameter Default Unit ID Description
A B C D E
P3.5.2.2.6 AI2 Signal Inver-
sion
0 0 0 0 0 398
P3.5.3.2.1 RO1 Function 2 2 2 49 2 11001 2 = Run
P3.5.3.2.4 RO2 Function 3 3 3 50 3 11004 3 = Fault
P3.5.3.2.7 RO3 Function 1 1 1 51 1 11007 1 = Ready
P3.5.4.1.1 AO1 Function 2 2 2 2 2 10050 2 = Output Fre-
quency
P3.5.4.1.2 AO1 Filter Time 1.0 1.0 1.0 1.0 1.0 s 10051
P3.5.4.1.3 AO1 Min Signal 0 0 0 0 0 10052
P3.5.4.1.4 AO1 Min Scale 0.0 0.0 0.0 0.0 0.0 10053
P3.5.4.1.5 AO1 Max Scale 0.0 0.0 0.0 0.0 0.0 10054
P3.10.1 Automatic Reset 0 0 1 1 1 731 0 = Disabled
1 = Enabled
P3.13.2.5 PID Setpoint
Selection
0 0 0 0 102 1047 0 = DigIN Slot0.1
102 = DigIN SlotA.
3
P3.13.2.6 PID Setpoint
Source 1
- - 1 1 1 332 1 = Keypad Set-
point 1
P3.13.2.10 PID Setpoint
Source 2
- - - - 2 431 2 = Keypad Set-
point 2
P3.13.3.1 PID Feedback
Function
- - 1 1 1 333 1 = Only Source1
in use
P3.13.3.3 PID Feedback
Source
- - 2 2 2 334 2 = AI2
P3.15.1 Multi-Pump
Mode
- - - 0 2 1785 0= Single drive
1= Multifollower
2= Multimaster
P3.15.2 Number of
Pumps
1 1 1 3 3 1001
VACON · 384 APPENDIX 1
12
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
