Vacon 100 flow Applications Manual

Table 12: M1 Quick setup
Index Parameter Min Max Unit Default ID Description
1.2 Application 0 4 2 212
0 = Standard
1 = HVAC
2 = PID Control
3 = Multi-pump (sin-
gle drive)
4 = Multi-pump
(multidrive)
1.3
Minimum
Frequency
Reference
0.00 P1.4 Hz 0.0 101
The minimum fre-
quency reference
that is accepted.
1.4
Maximum
Frequency
Reference
P1.3 320.0 Hz
50.0 /
60.0
102
The maximum fre-
quency reference
that is accepted.
1.5
Acceleration
Time 1
0.1 3000.0 s 5.0 103
Gives the quantity of
time that is neces-
sary for the output
frequency to
increase from 0 fre-
quency to the maxi-
mum frequency.
1.6
Deceleration
Time 1
0.1 3000.0 s 5.0 104
Gives the quantity of
time that is neces-
sary for the output
frequency to
decrease from the
maximum frequency
to 0 frequency.
1.7
Motor Cur-
rent Limit
I
H
*0.1 I
S
A Varies 107
The maximum motor
current from the AC
drive.
1.8 Motor Type 0 2 0 650
0 = Induction Motor
1 = Permanent Mag-
net Motor
2 = Reluctance
Motor
1.9
Motor Nom-
inal Voltage
Varies Varies V Varies 110
Find this value U
n
on
the nameplate of the
motor.
NOTE!
Find out if the
motor connection is
Delta or Star.
VACON · 68 QUICK STARTUP GUIDE
1
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
