17
Set the signal range of the analogue input
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
18
Set a value for P3.13.1.8 Error Inversion
0 = Normal
1 = Inverted
19
Set a value for P3.13.2.6 Setpoint Source Selection See table Setpoints in Table 75 Setpoint set-
tings
If you select an analogue input signal, step 20 shows first, and then step 22 shows. With
other selections, the wizard goes to step 21.
If you set Keypad Setpoint 1 or Keypad Setpoint 2 as the value, the wizard goes directly to step
22.
20
Set the signal range of the analogue input
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
21
Set a value for P3.13.2.1 (Keypad Setpoint 1) and
P3.13.2.2 (Keypad Setpoint 2)
Specified by the range set in step 19
22
Use the sleep function
0 = No
1 = Yes
If you give the value Yes in step 22, you see the next 3 steps. If you give the value No, the
wizard goes to step 26.
23
Set a value for P3.13.5.1 SP1 Sleep Frequency Limit Range: 0.00-320.00 Hz
24 Set a value for P3.13.5.2 SP1 Sleep Delay Range: 0-3000 s
25
Set a value for P3.13.5.3 SP1 Wake Up Level The range is specified by the set process
unit.
26 Set a value for P3.15.2 Number of pumps Range: 1-8
27
Set a value for P3.15.5 Pump Interlocking
0 = Not used
1 = Enabled
28
Set a value for P3.15.6 Autochange
0 = Disabled
1 = Enabled (Interval)
2 = Enabled (Weekdays)
If you set the value Enabled (Interval or Weekdays) to parameter Autochange, steps 29-34
show. If you set the value Disabled to parameter Autochange, the wizard goes directly to step
35.
WIZARDS VACON · 83
