13. TERMBOX Installation
13.1 Overview of TERMBOX Installation
TERMBOX is not used when the automatic weather station contains a solar panel or a
radio.
For AWS310, TERMBOX-1212 is available.
For AWS310-SITE, TERMBOX-1200 is available for 1 data line and TERMBOX-1212 for 2 data
lines.
More Information
‣
Placing TERMBOX (page 169)
‣
Installing TERMBOX on Pole Mast (page 170)
‣
Installing TERMBOX on Frangible Lattice Mast (page 172)
‣
Grounding TERMBOX (page 173)
‣
Grounding TERMBOX Signal Cable (page 174)
13.2
 Placing TERMBOX
The distance between the termination box and sensor input must not
exceed 5 meters (16 ft 5 in) along the cable.
CAUTION!
The TERMBOX delivery includes APPK-SET mounting kits of dierent sizes. Use the clamp
best suited to your mast.
To prevent corrosion and oxidation, use copper paste or equivalent on screws and
connector threads.
Chapter 13 – TERMBOX Installation
169
