.3 Mounting Half-length Sensor
Support Arm on DKP200
•
5
‑
mm Allen ke
y
•
13
‑
mm wrench
Figure 25 DKP12SUP1 Ins
tallation Acc
essories
1
Sensor support arm (10391)
2
U-bolt M8
3
Mounting plate
4
Flat washer A6.4 DIN125 A4 (
4 pcs)
5
Spring lock washer B6 DIN127 A4 (
4 pcs)
6
Hex scr
ew M6×16 DIN912 A4 (
4 pcs)
7
Spring lock washer B8 DIN127 A4 (
4 pcs)
8
Hex nut M8 DIN934 A4 (
4 pcs)
A
WS310
/
A
W
S310-SITE Installation Manual
