Do not remove the instrument or sensor from the mounting kit during alignment.
1. Use a compass or other similar method to measure the deviation angle from the North.
2. If possible, rotate the sensor on the mounting kit so that the transducer heads are
exactly in line with the compass and the North arrow points to the North.
3. Tighten the
fixing screw. Use a maximum of 1.5 Nm torque.
More Information
‣
Connecting Sensor and Device Cables (page 218)
6.3
Installing WMT700
Do not perform installation or maintenance procedures when there is a
risk of thunderstorm or lightning activity in the area.
WARNING!
To prevent equipment damage, install an air terminal so that the tip is as
high above the instruments and sensors as possible.
CAUTION!
Chapter 6 – Wind Sensor or Weather Transmitter Installation
49
