Make sure that the cable is properly attached to the mast or the sensor
support arm before you start the installation. Otherwise, it may slip and fall down during
the installation.
CAUTION!
1. Lead the wind sensor cable through the WMSFIX60 mounting adapter.
2. Holding the sensor from its body, connect the cable to the bottom part of the sensor.
6.5.2
 Aligning WXT520
2.5‑mm Allen key
WXT520 is permanently marked with the letter N and a North arrow at the bottom.
AWS310/AWS310-SITE Installation Manual M211584EN-F
72
