Change function Click this button to change the function for this indicator. The function can
be enabled or used for a system, area, zone or keyswitch.
Deactivation
Calendar Select if the keyswitch module should be limited by calendar.
Mapping gate Select if the keyswitch module should be limited by a mapping gate.
Output
Output x Configure and text the outputs for the keyswitch. See Editing an output on
page231 for more details.
Keyswitch Functions
Centre, Right and
Left Positions
Select the Function that that this keyswitch position will perform and the
relevant Area.
Keyswitch functions are:
l None
l Unset
l Partset A
l Partset B
l Fullset
l Toggle Unset / Fullset
l Toggle Unset / Partset A
l Toggle Unset / Partset B
l All Okay
l Setting authorisation
l Shunt
WARNING: Your system will not comply with EN standards if you enable a keyswitch function to
set the system without a valid PIN being required.
17.10.2.2 Keypads
Editing a Standard Keypad
1. Select Configuration > Hardware > X-Bus > Keypads.
2. Click one of the standard keypad identifying parameters.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 244 A6V10276959-d
11.2018
