VHF N4 Impression - Manufacturing Software & CAM Computer; Sound Emission; Technical Data

Machine description
10
Original instructions: N4 Impression
Document version: H – 05/2019
3.5 Manufacturing software & CAM computer
To operate the machine, you must use a computer running
Windows® (“CAM computer“) which is connected to the ma-
chine via the provided USB cable.
You can process manuf
acturing jobs with the CAM computer
in 2 steps:
1. With DentalCAM you can create jobs with the objects
that you want to machine. DentalCAM already contains
allimportantparametersforthedierentmaterials.
2. You can execute the jobs with the CNC software
DentalCNC. This application oers additional mainte
-
nance and control functions for the machine.
b
You must use a dierent computer together with a
scanner and suitable software to create the 3D models
of the objects (not provided, sold by specialist dealers).
3.6 Sound emission
The actual sound emission of the machine varies heavily de-
pending on the manufacturing material and the grinding
conditions.
h If the machine is too loud, check the operating condi
-
tions.
Ensurethattheblankisxedproperly,checkthe
condition of the tool and the material you use.
h If loud noise cannot be avoided, wear ear protection
during machining.
Sound measurement
Measuring conditions:

Processed material: VITABLOCS Mark II®

State of the tool: new

Distance to sound source: 1 m

Measurement according to ISO 3746, engineering
method 3
Operating condition Maximum A-weighted sound
pressure level
Processing 78 dB(A)
All other operating conditions
(tool change, movement of the
axes etc.)
<70 dB(A)
3.7 Technical data
Base system

Dimensions (W/D/H):

Footprint: approx. 340 x 320 mm (13.4 x 12.6 in)
Housing fully closed: approx. 360 x 450 x 470 mm
(14.2 x 17.7 x 18.5 in)

Housing fully open: approx. 360 x 690 x 470 mm
(14.2 x 27.2 x 18.5 in)

Weight: approx. 50 kg (110 lbs)

Recommended air pressure:4.5 bar (65 psi)

Compressed air consumption at recommended air
pressure: approx. 35 l/min (1.2 cfm)

Air purity according to ISO 8573-1:2010

4-axes mechanism; positioning range (x/y/z):
80 x 60 x 40 mm (3.2 x 2.4 x 1.6 in)

Built-in tank for cooling liquid in drawer shape with
coarseltermat,max.4.2l(4.4qt)

Complete housing of the working chamber; working
chamber door with a safety contact and safety interlock

Flow sensor for monitoring the cooling liquid circuit

Workingchamberlightingwithdierentcoloursto
indicate the machine state
Rotary axes

Rotational range: +190 ° to -10 °

Integrated blank holder for 3 blanks
Spindle

Synchronous spindle rotating up to 60,000 RPM

Nominal power under continous load (S1): 300 W

Nominal power under uninterrupted periodic operation
(S6): 450 W

Maximal Power (P
max
): 600 W

4-fold bearing

Hybrid ceramic ball bearing

Pneumatic collet chuck ø 3 mm

8 cooling liquid nozzles

Cone cleaning and sealing air
Tool magazines and tool change

Automatic tool change

8 tool positions distributed on 2 exchangeable tool
magazines

Maximum tool length: 35 mm

Automatic tool length measurement and tool breakage
monitoring via measuring key

Compressed air monitoring for the automatic tool
change
Cooling lubricant

Mix ratio with water: 1:19 (5% solution)

pH value of 9.5
