296
T A D D P
S1
S2
D
1
2
M
3
○○
FNC
162
○○
X Y M S
D.b R.b
KnX KnY
KnM KnS
T C
D,R
V,Z
UnG
K,H
E
" $"
S1
D
S2
TADD D0 D10 D20
X20
If the result of the time addition is exceeded 24 hours, the Carry Flag M9022 will be set “ON” and the will
display the value where 24 hours is subtracted from the total.
+
＝
＝
, also the M9022 = “ON”.
28-24=4
+
S1
S2
D
S1
S2
D
S1
S2
D
D
S1
S2
D
Operand
Devices
Time Addition
All the S1, S2 and D occupies 3 components respectively
S1 : the summand of the time combination
S2 : the addend of the time combination
D : the sum of the time combination
The designated time combination of the summand will be added to the designated time combination and
the combination of the sum will be stored at the assigned registers .
When X20 = “ON”, the instruction will be performed.
D0 = 8 (Hour)
D1 = 30 (Minute)
D2 = 0 (Second)
D10 = 6 (Hour)
D11 = 35 (Minute)
D12 = 30 (Second)
D20 = 15 (Hour)
D21 = 5 (Minute)
D22 = 30 (Second)
h m s
08 30 0
h m s
06 35 30
h m s
15 05 30
h m s
08 25 30
h m s
20 10 20
h m s
04 35 50
D0 = 8 (Hour)
D1 = 25 (Minute)
D2 = 30 (Second)
D10 = 20 (Hour)
D11 = 10 (Minute)
D12 = 20 (Second)
D20 = 4 (Hour)
D21 = 35 (Minute)
D22 = 50 (Second)
If the result of the time addition equals to “0” (0 hour 0 min 0 sec), then the Zero Flag M9020 will be set “ON”.
S1
S2
If the content value of the registers that designated by or exceeding the time value required, the PLC will
regard that as an operational error.
