1 - Coolant expansion tank
2 - Coolant circulation pump 2
- V178-
❑ Removing and installing
⇒ page 149
3 - ATF preheater
❑ Removing and installing
⇒ Rep. gr. 37
4 - Radiator outlet coolant -
G62-
5 - Temperature sender for en‐
gine temperature regulation -
G694-
❑ Removing and installing
⇒ page 151
6 - Coolant pump
7 - Coolant regulation valve -
N515-
1.4.2 Cooling system - assembly overview
part 2
Renew O-rings and seals.
Pull plug-in connector to make sure they are securely connected.
Specified torques:
Bolts, M6: 10 Nm
Bolts, M8: 20 Nm
