♦ M8x50 bolt
Removing:
– Press tensioning pulley in -direction of arrow- using a suitable
screwdriver.
– In the non-tensioned position, screw a M8×50 bolt into the
threaded hole -A-.
– Remove tensioning pulley for poly V-belt -arrows-.
– Disconnect connector of temperature sender - G694- and
move wire clear.
– Undo bolt for temperature sender - G694- using special
wrench - T10058- .
– Pull temperature sender - G694- out of cylinder head and re‐
move towards the front.
Caution
The O-ring and support washer can remain in cylinder head.
Check whether the temperature sender for engine temperature
regulation - G694- is »complete«.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
152 Rep. gr.19 - Cooling
To Next Page
