– Disconnect connectors on left and right from front speed sen‐
sors -arrow-.
– Disconnect connector -arrow- for wear indicator.
– Remove bolts -arrows- for cable retainers.
– Unscrew bolts -1- for brake caliper.
Note
Do not attempt to bend brake lines to a different shape.
– Suspend brake caliper in wheel housing with wire.
Caution
Avoid damage to brake pistons.
♦ Do not press brake pedal when brake caliper is removed.
– Unscrew nut for suspension link at top by several turns and
push off articulated joint together with ball joint puller -
T10187- .
– Completely unscrew nut and detach suspension link.
