Note
Attach cable ties in all the same places when installing.
– Detach hoses -1- and -2- and remove air pipe -arrows-.
– Separate electrical connector -1- on throttle valve module -
J338- .
– Remove bolts -arrows- and detach throttle valve module -
J338- .
– Remove vacuum lines at intake manifold as follows:
1 - For activated charcoal filter, press release buttons
3 - For brake servo -arrow-
Note
Disregard -item 2-.
– Remove air filter upper part.
– Undo bolts -arrow- and remove bracket.
– Undo bolts -1 and 2- and remove heat shield.
