– Undo bolt for catalytic converter of exhaust bank 2 -arrow-
from below.
– Undo bolts for catalytic converter of exhaust bank 1 -arrow-
from below.
– Undo nuts -arrows- and pull primary catalytic converters off
exhaust manifolds.
– Undo 6 nuts on each of the two exhaust manifolds -arrows-
and remove exhaust manifolds.
Installing:
• Specified torques ⇒ page 253 .
Install in reverse order of removal, observing the following:
Note
♦
Renew seals, gaskets and self-locking nuts.
♦
Coat studs with high temperature paste - G 052 112 A3- .
– Install catalytic converter ⇒ page 260 .
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
1. Exhaust manifold 255
