– Put on support bracket as shown.
Caution
Support bracket is not allowed to be placed on metal tabs
-arrow-!
– Push articulated joint - T40093/4- as well as adapter - 10 - 222
A /28- onto square tube - T40091/1- .
– Place adapter - 10 - 222 A /28- onto longitudinal member and
push square tube - T40091/1- into articulated joint -
T40091/3- .
– Repeat procedure on opposite side of vehicle.
– Push hook rail - T40091/2- on one side through articulated joint
- T40093/4- .
– Push mounting - T40093/5- onto the hook rail - T40091/2- then
slide hook rail onto other side of rotary joint.
– Set retaining pin and secure with split pins.
– Tighten all threaded connections of support bracket by hand.
– Insert hooks of spindles into the engine lifting eyes and brace
engine in installation position.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
26 Rep. gr.10 - Removing and installing engine
