9 - Sprocket
❑ For timing chains
❑ Install camshaft adjuster with camshaft timing chain ⇒ page 64 .
10 - Camshaft timing chain
❑ Before removing, mark direction of rotation (installation position) ⇒ page 32 .
❑ Install camshaft adjuster with camshaft timing chain ⇒ page 64 .
11 - 60 Nm +
1
/
4
turn (90°) further
❑ Renew
12 - Exhaust camshaft adjuster
❑ Identification: 32A.
❑ Install camshaft adjuster with camshaft timing chain ⇒ page 64 .
13 - 60 Nm +
1
/
4
turn (90°) further
❑ Renew
❑ Contact surface of sender wheel must be dry around bolt head when installed.
❑ To remove and install, counterhold using 27 mm open-end spanner on camshaft ⇒ page 105 , Removing
and installing camshafts.
14 - Inlet camshaft adjuster
❑ Identification: 24E
❑ Install camshaft adjuster with camshaft timing chain ⇒ page 64 .
15 - 10 Nm
16 - Chain tensioner with tensioning rail
❑ For timing chain ⇒ Item 19 (page 31)
❑ Only rotate engine when chain tensioner is installed.
17 - Drive gear
❑ Built into crankshaft.
❑ Ground down tooth aligned with main bearing joint = TDC No. 1 cylinder, Adjusting timing chain for oil
pump drive ⇒ page 74 .
18 - Locating pin without collar, 10 Nm
❑ For guide rail ⇒ Item 23 (page 31) .
19 - Timing chain
❑ Before removing, mark direction of rotation (installation position) ⇒ page 32 .
❑ Installing timing chain for oil pump drive ⇒ page 74 .
20 - Pivot pin, 10 Nm
❑ for guide rail
21 - 23 Nm
22 - Slide rail
❑ For camshaft timing chain ⇒ Item 10 (page 31)
23 - Slide rail
❑ For timing chain ⇒ Item 19 (page 31)
❑ Remove and install together with timing chain. Installing timing chain for oil pump drive ⇒ page 74 .
24 - Drive sprocket for high pressure pump
❑ With needle bearing
❑ Lubricate needle bearing before installing.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
1. Dismantling and assembling engine 31
