8 - 60 Nm + turn 90° further
❑ Renew
9 - 8 Nm
❑ Insert with locking fluid - D 000 600 A2-
10 - 20 Nm
❑ The specified torque influences the function of the knock sensor.
11 - Knock sensor 1 - G61-
❑ Fitting location: between cylinder 1 and cylinder 3 below exhaust manifold.
12 - Seal
❑ Renew
13 - Oil intake tube
❑ For oil pump.
14 - O-ring
❑ Renew
15 - 8 Nm
❑ Insert with locking fluid - D 000 600 A2-
16 - Oil pressure pipe
17 - 8 Nm
❑ Insert with locking fluid - D 000 600 A2-
18 - Oil drain plug, 30 Nm
❑ With captive seal
❑ Renew
19 - Sump
❑ Removing and installing ⇒ page 119
20 - Oil level and oil temperature sender - G266-
21 - 12 Nm
22 - Securing bolt for oil sump
❑ 10 Nm
23 - Oil filter housing / left engine bracket
❑ Dismantling and assembling ⇒ page 128
❑ Connection diagram for coolant hoses ⇒ page 135
❑ Removing left or right engine mountings ⇒ page 27
24 - 23 Nm
25 - Ancillary bracket
❑ For alternator, air conditioner compressor and power-assisted steering vane pump
26 - Engine speed sender - G28-
❑ Removing and installing ⇒ page 274
27 - 10 Nm
28 - O-ring
❑ Renew
29 - 25 Nm
30 - 20 Nm
❑ The specified torque influences the function of the knock sensor.
31 - Knock sensor 2 - G66-
❑ Fitting location: between cylinder 4 and cylinder 6.
