2-20 SHB WL34 * 2.0
2 Engine
Fuel tank
2.4 Removing/installing the fuel tank
Preparing work
Tools:
• Suitable receptacles for collecting the fuel
Technical data
Use a suitable container to collect the fuel as it drains off and dispose of it
in an environmentally friendly manner!
Crushing hazard during work under the loader unit
A loader unit suddenly falling down can cause serious injury or death.
► Install safety props when working under the raised loader unit.
1. Raise the loader unit.
2. Stop the diesel engine and remove the starting key.
3. Mount the safety prop.
Designation Value
Fuel tank 5.5 kg
Engine
Fuel tank
