E-24 SHB WL34 * 2.0
E Introduction
Tightening torques
Tightening torques for brake line screw connections
Form F socket unions and Form FS socket unions with flange
Tightening torques for worm drive hose clamps
Tightening torques for spring-loaded worm drive hose clamps
Dimension Tightening torque in Nm
M10 x 1 14+2
Clamp width
Tightening torques for first-time
installation of new hoses
Tightening torques for re-tighten-
ing or reassembly
7.9 mm (0.31 in) 0.9 ± 0.2 Nm (8 ± 2 lb in) 0.7 ± 0.2 Nm (6 ± 2 lb in)
13.5 mm (0.53 in) 4.5 ± 0.5 Nm (40 ± 4 lb in) 3.0 ± 0.5 Nm (27 ± 4 lb in)
15.9 mm (0.63 in) 7.5 ± 0.5 Nm (65 ± 4 lb in) 4.5 ± 0.5 Nm (40 ± 4 lb in)
Clamp width Clamp diameter Tightening torque
12 mm 60 - 80 mm 5 + 0.5 Nm
12 mm 70 - 90 mm 5 + 0.5 Nm
