Wacker Neuson WL34 - Vibration

SHB WL34 * 2.0 E-9
Introduction E
Technical data
Vibration
Information on vibration
Hand/arm vibrations:
Hand-arm vibrations do not exceed 2.5 m/s² (98.42 in/s²).
Full-body vibrations:
This machine is equipped with an operator's seat that complies with EN
ISO 7096:2000 requirements.
When the machine is used in accordance with its designated use, full-
body vibrations vary from less than 0.5 m/s² (19.69 in/s²) up to a
momentary maximum value.
When calculating the vibration values in accordance with ISO/TR
25398:2006, you are advised to use the values specified in the table. Here
the actual conditions of use must be taken into account.
Telescopic wheel loaders, like wheel loaders, are classified according to
their operating weight.
Machine category
Typical operating
conditions
Average value Standard deviation (s)
1.4*aw,eqx 1.4*aw,eqy aw,eqz 1.4*sx 1.4*sy sz
Compact loader
operating weight
< 4500 kg
(9920.8 lbs.)
Load & carry
(loading and
transportation
work)
0.94 m/s²
(3.08 ft/s²)
0.86 m/s²
(2.82 ft/s²)
0.65 m/s²
(2.13 ft/s²)
0.27 m/s²
(0.89 ft/s²)
0.29 m/s²
(0.95 ft/s²)
0.13 m/s²
(0.43 ft/s²)
Wheel loader
operating weight
> 4500 kg
(9920.8 lbs.)
Load & carry
(loading and
transportation
work)
0.84 m/s²
(2.76 ft/s²)
0.81 m/s²
(2.66 ft/s²)
0.52 m/s²
(1.71 ft/s²)
0.23 m/s²
(0.76 ft/s²)
0.20 m/s²
(0.66 ft/s²)
0.14 m/s²
(0.46 ft/s²)
Use in extraction
(harsh conditions
of use)
1.27 m/s²
(4.17 ft/s²)
0.97 m/s²
(3.18 ft/s²)
0.81 m/s²
(2.66 ft/s²)
0.47 m/s²
(1.54 ft/s²)
0.31 m/s²
(1.02 ft/s²)
0.47 m/s²
(1.54 ft/s²)
Transfer travel
0.76 m/s²
(2.49 ft/s²)
0.91 m/s²
(2.99 ft/s²)
0.49 m/s²
(1.61 ft/s²)
0.33 m/s²
(1.08 ft/s²)
0.35 m/s²
(1.15 ft/s²)
0.17 m/s²
(0.56 ft/s²)
V-shape operation
(loading)
0.99 m/s²
(3.25 ft/s²)
0.84 m/s²
(2.76 ft/s²)
0.54 m/s²
(1.77 ft/s²)
0.29 m/s²
(0.95 ft/s²)
0.32 m/s²
(1.05 ft/s²)
0.14 m/s²
(0.46 ft/s²)
