9-34 SHB WL34 * 2.0
9 Electrical system
Designation of electrical components
9.27 Designation of electrical components
Component list
Designation
A Assemblies
A001 Radio
B Converter
B001 Fuel indicator
B002 Horn
B003 Reversing warning system
B006 Engine temperature sensor
B008 Load sensor ā strain gage
B011 Loudspeaker
B012 Loudspeaker
B041 3rd control circuit scroll wheel
B042 Scroll wheel for forward/reverse travel
B054 Accelerator pedal
B074 Scroll wheel additional control circuit
B113 Manual throttle
ELights
E001 Front right side marker light
E002 Rear right light
E003 Front left parking light
E004 Rear left light
E007 Rear working light
E008 Rear working light
E009 Front working lights
E010 Front working lights
E014 Interior light
E016 Numberplate light
E024 Low beam (right)
E025 Low beam (left)
E026 High beam (right)
E027 High beam (left)
F Fuses ā see "Fuse assignment" on page 9-2
Electrical system
Designation of electrical components
