SHB WL34 * 2.0 9-35
Electrical system 9
Designation of electrical components
G Power supply
G001 Generator
G002 Battery
H Control, signal and indicating devices
H001 High beam indicator light
H002 Preheating indicator light
H003 Engine temperature indicator light
H004 Engine oil pressure indicator light
H005 Alternator charge function indicator light
H006 Air filter indicator light
H007 Hydraulic oil filter indicator light
H008 Hydraulic oil temperature indicator light
H016 Forward travel indicator light
H017 Reverse travel indicator light
H018 Check parking brake
H020 Brake lights
H021 Brake lights
H022 Machine turn indicator light
H024 Front right turn indicator
H025 Rear right turn indicator
H026 Front left turn indicator
H027 Rear left turn indicator
H028 Rotating beacon
H052 High-speed Vgmax indicator light (hare)
H053 Creep gear indicator light Vgmin (turtle)
K Relays
K001
High current relay fitting
K002
High current relay F026
K005 High current relay, preheating
K006 Preheating relay
K007 Start high-current relay
K010 Turn indicator relay
K042 Engine electronics switching relay
K047 Working light relay
K058 1st/2nd speed switching relay
K088 Fuel pump switching relay
K089 Switching relay DPF pump (Perkins-404F)
Designation
