Wacker Neuson WL34 - Tightening Torques for Hydraulic Screw Struts SDS

E-18 SHB WL34 * 2.0
E Introduction
Tightening torques
Tightening torques for hydraulic screw struts SDS
Shape B with sealing edge (cutting edge) and shape E with soft
O-ring seal
Dimension
Tightening torque
(light-weight series)
in Nm
Tightening torque
(heavy-weight series)
in Nm
M5 - -
M6 - -
M8 x 1 - -
M10 x 1 18 -
M12 x 1.5 30 35
M14 x 1.5 45 55
M16 x 1.5 60 70
M18 x 1.5 70 110
M20 x 1.5 - 140
M22 x 1.5 140 170
M26 x 1.5 180 220
M27 x 2 190 250
M33 x 2 300 300
M42 x 2 500 550
M48 x 2 550 600
G 1/8 A 20 25
G 1/4 A 35 40
G 3/8 A 70 90
G 1/2 A 100 150
G 3/4 A 180 270
G 1 A 250 350
G 1-1/4 A 450 500
G 1-1/2 A 550 600
7/16 - 20 (11.1 mm) - -
1/2-20 (UNF) - -
9/16 - 18 (14.3 mm) - -
3/4 - 16 (19.1 mm) - -
7/8 - 14 (22.2 mm) - -
1-1/16 - 12 (27 mm) - -
1-5/16 - 12 (33.3 mm) - -
1-5/8-12 (UNF) - -
1-7/8 - 12 (UNF) - -
2 - 12 (UNF) - -
