E-14 SHB WL34 * 2.0
E Introduction
Tightening torques
Torque values for metric coarse-pitch thread
Screws and nuts
The tightening torques specified below only apply if:
• A friction coefficient of μ
tot
= 0.14 is reached in connection with a
thread lubricant. A surface protection, for example A3C+L, Dacromet
or Termosil, is recommended for this.
• No other tightening torque is specified in the text.
• No additional screw locks, for example MK screws or a liquid screw
lock, are used.
Tightening torques in Nm
Property class 8.8 10.9 12.9
Designation Dimensions
Hexagon head cap screw
ISO 4014 to
ISO 4018
Cheese-head screws
ISO 4762
Hexagon nuts
ISO 4032
M4 2.9 4.3 5
M5 5.8 8.5 10
M6 10 14.5 17
M8 24.5 36 42
M10 48.57183.5
M12 83.5 123 144
M14 133 196 229
M16 207 304 355
M18 296 422 494
M20 417 594 695
M22 570 813 951
M24 718 1022 1196
M27 1058 1506 1763
M30 1437 2046 2395
M33 1944 2770 3240
M36 2500 3561 4167
M39 3237 4610 5394
