Wacker Neuson WL34 - Central Lubrication System Diagram

SHB WL34 * 2.0 1-25
Maintenance 1
Maintenance
Central lubrication system diagram
31
15
BK
BN (YE/GR)
OR
RD
GN
GN
RD
1
3
2
4
Item Designation
1 Option external signal lamps
2 Option filling level switch which for monitoring the grease level
3 Option microswitch for pressure relief valve check
4 Push button – intermediate lubrication
