SHB WL34 * 2.0 9-39
Electrical system 9
Designation of electrical components
Cable colors
Y022 Tilt cylinder lock solenoid valve
Y023 Solenoid valve retract telescopic boom/4th control circuit
Y024 Solenoid valve extend telescopic boom/4th control circuit
Y025 Quickhitch lock solenoid valve
Y030 Solenoid valve cold start
Y033 Solenoid valve 3rd control circuit
Y034 Solenoid valve 3rd control circuit
Y094 Solenoid valve (boom interlock 1)
Y095 Solenoid valve (boom interlock 2)
Y108 Solenoid valve roll-in stop
Y119 Solenoid valve (loader unit stabiliser)
Y149 Solenoid valve comfort control
Designation
Abbreviation Designation
BK Black
BN Brown
BU Blue
GD Gold
GN Green
GY Gray
OG Orange
PK Pink
RD Red
SR Silver
TQ Turquoise
VT Violet
WH White
YE Yellow
