Wacker Neuson WL34 - Tightening Torques for Adjustable Hydraulic Screw Struts SDE

E-22 SHB WL34 * 2.0
E Introduction
Tightening torques
Tightening torques for adjustable hydraulic screw struts SDE
Shape F with O-ring
Dimension
Tightening torque
(very light-weight series)
in Nm
Tightening torque
(light-weight series)
in Nm
Tightening torque
(heavy-weight series)
in Nm
M8 x 1---
M10 x 1 20 15 -
M12 x 1.5 - 25 35
M14 x 1.5 - 35 45
M16 x 1.5 - 40 55
M18 x 1.5 - 45 90
M20 x 1.5 - - 140
M22 x 1.5 - 60 170
M26 x 1.5 - 100 190
M27 x 2 - 100 190
M33 x 2 - 160 310
M42 x 2 - 210 330
M48 x 2 - 260 420
7/16 - 20 (11.1 mm) - 15 20
1/2-20 (UNF) - 30 40
9/16 - 18 (14.3 mm) - 35 45
3/4 - 16 (19.1 mm) - 55 60
7/8 - 14 (22.2 mm) - 80 90
1-1/16 - 12 (27 mm) - 100 100
1-5/16 - 12 (33.3 mm) - 150 170
1-5/8-12 (UNF) - 290 340
1-7/8 - 12 (UNF) - 325 415
2 - 12 (UNF) - 350 450
