Wacker Neuson WL34 - Removing;Installing Cover for Rear Wall Cladding; Removing;Installing Filler Cap for the Control Console

SHB WL34 * 2.0 1-19
Maintenance 1
Maintenance
Removing/installing cover for rear wall cladding
1. Remove the operator seat – see "Removing/installing the operator
seat" on page 1-18.
2. Remove all screws and take off the cover plate 1.
Install in the reverse order.
Removing/installing filler cap for the control console
Inside
1. Remove the operator seat – see "Removing/installing the operator
seat" on page 1-18.
2. Remove all screws and take off the cover plate 1.
Install in the reverse order.
Outer side
1. Remove all screws and take off the cover plate 1.
Install in the reverse order.
Fig. 21
1
Fig. 22
1
Fig. 23
1
