E-12 SHB WL34 * 2.0
E Introduction
Technical data
Pos. Designation
Value
mm Inches
A Overall length with standard bucket 4932 194.17
Overall length without attachment 4135 162.80
B Center of axle to bucket pin 675 26.57
C Wheelbase 2045 80.51
D Rear overhang 1311 51.61
E* Load-over height 2877 113.27
F* Max. height of bucket pivot point 3239 127.52
G* Seat height 1293 50.91
H* Max. tilt-out height 2360 92.91
I* Scraping depth 132 5.20
K* Reach at H 153 6.02
L*
Height above high protective roof 2317 91.22
Height above low protective roof 2214 87.17
Height above high cabin 2359 92.87
Height above low cabin 2257 88.86
M* Overall working height 3978 156.61
N Max. tilt-out angle at max. lifting height 43°
O Roll back angle at ground 45°
P Roll back angle at max. lift height 44°
Q* Inner radius 1827 71.93
R* Overall width 1410 55.51
S* Radius at outer edge 3271 128.78
T* Ground clearance 297 11.69
U Articulation angle 44°
V Width across protective roof for operator/cabin 1146 45.12
W* Track width 1132 44.57
Z
Maximum radius
(depends on bucket width)
3689 145.24
All dimensions with tires 11.5/80-15.3 AS
*Dimensions differ if other tires or reversed wheel rims are used
