8-32 SHB WL34 * 2.0
8 Hydraulic system
Diagrams
Equipment variant 2: HDM19/4
Option:
Float position
Load stabilizer
Lift cylinder with counterbalance valve
Pressure-free reverse travel/leakage pipe
3rd control circuit comfort
4th control circuit 4-times valve
Differential lock
Legend
Item Description
1 Rear machine section
2 Front chassis section
3 4th control circuit, connection for front attachments
4 3rd control circuit, connection for front attachments
5 3rd control circuit right
6 3rd control circuit left
7 Lower
8Raise
9 Unroll
10 Roll up
11 Center joint
12
Engine options:
- 404D-22 (35.7 kW)
- 404F-22 (35.7 kW)
- TD2011 L04W (55.1 kW)
13 Front-axle drum brake
14 Foot operation
15 To manifold
16 Front axle differential lock
17 Rear axle differential lock
18 Manifold
19 Return without pressure, optional at front or rear
20 Leak oil line
