Wacker Neuson WL34 - Page 317

SHB WL34 * 2.0 11-11
Cabin 11
Wiper motor
11.5 Removing/installing the wiper motor
1. Move the windshield wiper to center position.
2. Remove screws 1.
3. Pull the steering column completely to the rear and remove the cover.
4. Disconnect plug connection 2.
5. Remove screw 3.
6. Remove three screws 4.
7. Remove the wiper motor.
Install in the reverse order.
Fig. 300
1
Fig. 301
1
Fig. 302
2
Fig. 303
3
4
