B Operation
Overview of control elements
Position Designation
1 Brake/inching pedal
2 Steering-column control lever – control lever for lights, turn indicators and alarm
3 Steering wheel
4 Display instrument
5 Ignition lock
6 Cabin heating
7 Accelerator pedal
8 Switch panel 2
9 Lock for the road travel lock
10 Loader unit control lever
11 Control lever for auxiliary hydraulics (3rd control circuit)
12 Control lever for manual throttle (optional)
13 Radio
14 Operator seat
15 Parking brake control lever
16 Switch panel 1
Control elements not shown in overview
17 Switch panel 3 (on the right on the cabin roof)
