B-6 SHB WL34 * 2.0
B Operation
Overview of control elements
Information
Switch panel assignment may differ depending on machine configuration.
Fig. 12
51
52
53
54
50
49
Switch panel 2
49 Diesel particulate filter switch (option)
50 Not assigned
51 Switch for rear hydraulic connection (option)
52 Switch for continuous operation of 3rd control circuit (option)
53
Switch for float-position/
loader unit stabilizer (option)
54 Switch for loader unit lock
Fig. 13
55
56
57
Switch panel 3 (on the right on the cabin roof)
55 Not assigned
56 Rear window heating switch (option)
57 Rear wiper/washer system switch (option)
