1-14 SHB WL34 * 2.0
1 Maintenance
Maintenance
Item Lubrication point Number of zerks
1 Engine cover hinges [2]
2 Brake pedal bearing (in cabin) [1]
3 Accelerator pedal (in cabin) [1]
4 Upper center-joint bearing [1]
5 Rear lift cylinder [2]
6 Loader unit bearing [2]
7 Rear tilt cylinder [1]
8 Front lift cylinder [2]
9 Front tilt cylinder [1]
10 Bearing of large reversing lever [2]
11 Large front traction bar [1]
12 Small rear traction bar [1]
13 Small front traction bar [1]
14 Rear cardan shaft [1]
15 Upper center-joint bearing (remote lubrication in left access) [1]
16 Rear steering cylinder (remote lubrication in left access) [1]
17 Lower center-joint bearing [1]
18 Front steering cylinder [1]
19 Front cardan shaft [1]
20 Large rear traction bar [1]
21 Bearing of small reversing lever [1]
22 Pivot point of quickhitch [2]
23 Pin for hydraulic locking of attachments [2]
Lubricate all lubrication points every 20 operating hours with water resistant multi-purpose grease! Lubricate all
other moving parts such as the parking-brake lever, pedals, Bowden cables, etc. with an oil can!
See Lubrication work on page 1-22 for more lubrication information.
