WAREMA climatronic - Page 41

890370_0•en•01.06.2009 We reserve the right to carry out improvements
41
Humidity and
temperature
sensor
Output to next component
Input from previous component
JY(St)Y 2x2x0.8mm ø
wt
wt
yl
yl
bk
bk
rd
rd
Status-
LED
Programming
pushbutton
X5
X6
0V 24V
Supply
wt
yl
A B
RS 485
bk rd
Fig. 19 Connection example of humidity/temperature sensor
Connection information
