WSTECH APS Series - Figure 87: DC Connection; Figure 88: DC Connection

Original Operating Instructions
APS Series – Outdoor Hybrid Inverter
Installation
APS-Series 120 Operating Instructions v320 EN
Page 107 of 213
Figure 87: DC connection (1000 V
DC
) (detail view)
Pos.
Description
1
Safety lock washer
2
Cable lug (not included in scope of delivery)
3
Hexagon nut
4
Hexagon screw (pressed-in)
Figure 88: DC connection (1500 V
DC
) (detail view)
Pos.
Description
1
Safety lock washer
2
Cable lug (not included in scope of delivery)
3
Hexagon screw
