Table 15: Ampacity of AC terminals (APS with 1 APU)
Pos.
AC Connection
Divide of APS nominal current
1
L1. APU 1
1 times APU current
2
L2. APU 1
1 times APU current
3
L3. APU 1
1 times APU current
Table 16: Ampacity of AC terminals (APS with 2 APUs)
Pos.
AC Connection
Divide of APS nominal current
1
L1. APU 1
1 times APU current
2
L1. APU 2
1 times APU current
3
L2. APU 1
1 times APU current
4
L2. APU 2
1 times APU current
5
L3. APU 1
1 times APU current
6
L3. APU 2
1 times APU current
Table 17: Ampacity of AC terminals (APS with 3 APUs)
Pos.
AC Connection
Divide of APS nominal current
1
L1. APU 2
1 times APU current
2
L2. APU 2
1 times APU current
3
L3. APU 2
1 times APU current
4
L1. APU 3
1 times APU current
5
L1. APU 4
1 times APU current
6
L2. APU 3
1 times APU current
7
L2. APU 4
1 times APU current
8
L3. APU 3
1 times APU current
9
L3. APU 4
1 times APU current
Table 18: Ampacity of AC terminals (APS with 4 APUs)
Pos.
AC Connection
Divide of APS nominal current
1
L1. APU 1 + 2
2 times APU current
2
L2. APU 1 + 2
2 times APU current
3
L3. APU 1 + 2
2 times APU current
4
L1. APU 3
1 times APU current
5
L1. APU 4
1 times APU current
6
L2. APU 3
1 times APU current
7
L2. APU 4
1 times APU current
8
L3. APU 3
1 times APU current
9
L3. APU 4
1 times APU current
