4.2.2 Surfaces
Figure 40: Height and length definition of APS
Table 9 shows the surfaces of the APS with 1-2 APUs and 3-4 APUs.
Table 9: Surfaces of the APS
Part of the APS
Surface
description
APS with 1-2 APUs
(values in m
2
)
APS with 3-4 APUs
(values in m
2
)
Complete APS
Height x Length
5.178
9.875
Complete APS
Height x Width
3.216
3.338
4.2.3 Centroid (Geometric Centre)
The centroid of the APS is given from the bottom side of the APS carrier. For the
calculating of the torque only the height is required. All dimensions given in millimetre.
Figure 41: Centroid (geometric centre) (APS
with 1-2 APUs)
Figure 42: Centroid (geometric centre) (APS with 3-4
APUs)
